Train models like a pro with NVIDIA TLT 3.0

Train fast and accurate computer vision models with NVIDIA’s Transfer Learning Toolkit 3.0; a no-code interface to train and deploy models with TensorRT acceleration.

Photo by Snapwire from Pexels | Logo by NVIDIA
Image by NVIDIA

Introduction

This blog will help you set-up dependencies for TLT 3.0 and run through examples of training, pruning, re-training and exporting your models. (Perhaps dive into INT8 optimization too!) This might be a long blog, so brace yourselves. I will include pictures along the way to hold on to your attention! Just kidding.

Install Dependencies

Assuming you are running Ubuntu 20.04 LTS, you will need CUDA 11.2, nvidia-docker and a few other dependencies.

CUDA 11.2

Begin with downloading the deb file from the CUDA repository based on your platform.

Image by author | CUDA platform selection
wget https://developer.download.nvidia.com/compute/cuda/repos/ubuntu2004/x86_64/cuda-ubuntu2004.pinsudo mv cuda-ubuntu2004.pin /etc/apt/preferences.d/cuda-repository-pin-600wget https://developer.download.nvidia.com/compute/cuda/11.2.1/local_installers/cuda-repo-ubuntu2004-11-2-local_11.2.1-460.32.03-1_amd64.debsudo dpkg -i cuda-repo-ubuntu2004-11-2-local_11.2.1-460.32.03-1_amd64.debsudo apt-key add /var/cuda-repo-ubuntu2004-11-2-local/7fa2af80.pubsudo apt updatesudo apt -y install cudasudo reboot
Image by author | nvidia-smi

Docker

Docker is a platform that helps in the containerization of apps by providing OS-level virtualization.

sudo apt-get remove docker docker-engine docker.io containerd runc
sudo apt-get update

sudo apt-get install \
apt-transport-https \
ca-certificates \
curl \
gnupg
curl -fsSL https://downloads.docker.com/linux/ubuntu/gpg | sudo gpg — dearmor -o /usr/share/keyrings/docker-archive-keyring.gpg
echo \
"deb [arch=amd64 signed-by=/usr/share/keyrings/docker-archive-keyring.gpg] https://download.docker.com/linux/ubuntu \
$(lsb_release -cs) stable" | sudo tee /etc/apt/sources.list.d/docker.list > /dev/null
sudo apt-get update
sudo apt-get install docker-ce docker-ce-cli containerd.io
sudo docker run hello-world
Image by author | Docker Hello World
sudo groupadd docker
sudo usermod -aG docker $USER
newgrp docker

nvidia-docker2

nvidia-docker2 helps to bridge the GPU to docker containers.

distribution=ubuntu20.04curl -s -L https://nvidia.github.io/nvidia-container-runtime/experimental/$distribution/nvidia-container-runtime.list | sudo tee /etc/apt/sources.list.d/nvidia-container-runtime.listsudo apt-get updatesudo apt-get install -y nvidia-docker2sudo systemctl restart dockersudo docker run --rm --gpus all nvidia/cuda:11.0-base nvidia-smi

TLT Python packages

These python packages help in pulling containers and mounting targets.

sudo apt install python3-dev python3-pip
pip3 install nvidia-pyindex
pip3 install nvidia-tlt
pip3 install jupyter

NVIDIA container registry login

This step is vital to access containers from NVIDIA. Sign up at https://ngc.nvidia.com/signin and generate an API Key to login.

docker login nvcr.io

Train your first model!

Photo by Jovana Askrabic on Unsplash
# SSH
git clone git@github.com:aj-ames/nvidia-tlt-get-started.git
# HTTPS
git clone https://github.com/aj-ames/nvidia-tlt-get-started.git
➜ tree
.
├── train
│ └── cat
│ └── ...
│ └── dog
│ └── ...
├── val
│ └── cat
│ └── ...
│ └── dog
│ └── ...
├── test
│ └── ...
jupyter notebook --ip 0.0.0.0 --port 8888 --allow-root
Image by author | Jupyter Notebook in VS Code

Experiment yourself?

Remember I mentioned that NVIDIA has a repository of scripts? Go ahead and download it in the following way —

wget --content-disposition https://api.ngc.nvidia.com/v2/resources/nvidia/tlt_cv_samples/versions/v1.0.2/zip -O tlt_cv_samples_v1.0.2.zipunzip -u tlt_cv_samples_v1.0.2.zip  -d ./tlt_cv_samples_v1.0.2 && rm -rf tlt_cv_samples_v1.0.2.zip && cd ./tlt_cv_samples_v1.0.2
➜ tree
.
├── augment
│ ├── augment.ipynb
│ └── specs
│ └── default_spec.txt
├── classification
│ ├── classification.ipynb
│ └── specs
│ ├── classification_retrain_spec.cfg
│ └── classification_spec.cfg
├── deps
│ └── requirements-pip.txt
├── detectnet_v2
│ ├── detectnet_v2.ipynb
│ ├── __init__.py
│ └── specs
│ ├── detectnet_v2_inference_kitti_etlt_qat.txt
│ ├── detectnet_v2_inference_kitti_etlt.txt
│ ├── detectnet_v2_inference_kitti_tlt.txt
│ ├── detectnet_v2_retrain_resnet18_kitti_qat.txt
│ ├── detectnet_v2_retrain_resnet18_kitti.txt
│ ├── detectnet_v2_tfrecords_kitti_trainval.txt
│ └── detectnet_v2_train_resnet18_kitti.txt
├── dssd
│ ├── dssd.ipynb
│ ├── __init__.py
│ └── specs
│ ├── dssd_retrain_resnet18_kitti.txt
│ ├── dssd_tfrecords_kitti_trainval.txt
│ └── dssd_train_resnet18_kitti.txt
├── emotionnet
│ ├── ckplus_convert.py
│ ├── dataset_specs
│ │ └── dataio_config_ckplus.json
│ ├── emotionnet.ipynb
│ └── specs
│ ├── emotionnet_tlt_pretrain.yaml
│ └── emotionnet_tlt.yaml
├── facenet
│ ├── convert_wider_to_kitti.py
│ ├── facenet.ipynb
│ └── specs
│ ├── facenet_inference_kitti_etlt.txt
│ ├── facenet_inference_kitti_tlt.txt
│ ├── facenet_retrain_resnet18_kitti.txt
│ ├── facenet_tfrecords_kitti_train.txt
│ ├── facenet_tfrecords_kitti_val.txt
│ └── facenet_train_resnet18_kitti.txt
├── faster_rcnn
│ ├── faster_rcnn.ipynb
│ └── specs
│ ├── default_spec_darknet19.txt
│ ├── default_spec_darknet53.txt
│ ├── default_spec_efficientnet_b0.txt
│ ├── default_spec_googlenet.txt
│ ├── default_spec_mobilenet_v1.txt
│ ├── default_spec_mobilenet_v2.txt
│ ├── default_spec_resnet101.txt
│ ├── default_spec_resnet10.txt
│ ├── default_spec_resnet18_grayscale.txt
│ ├── default_spec_resnet18_retrain_spec.txt
│ ├── default_spec_resnet18.txt
│ ├── default_spec_resnet34.txt
│ ├── default_spec_resnet50.txt
│ ├── default_spec_vgg16.txt
│ ├── default_spec_vgg19.txt
│ └── frcnn_tfrecords_kitti_trainval.txt
├── fpenet
│ ├── data_utils.py
│ ├── fpenet.ipynb
│ ├── __init__.py
│ └── specs
│ ├── dataset_config.yaml
│ ├── experiment_spec.yaml
│ └── inference_sample.json
├── gazenet
│ ├── face_model_nv68.py
│ ├── gazenet.ipynb
│ ├── mpiifacegaze_convert.py
│ ├── sample_labels
│ │ └── data_factory.zip
│ ├── specs
│ │ ├── gazenet_tlt_pretrain.yaml
│ │ └── gazenet_tlt.yaml
│ └── utils_gazeviz.py
├── gesturenet
│ ├── convert_hgr_to_tlt_data.py
│ ├── gesturenet.ipynb
│ ├── __init__.py
│ └── specs
│ ├── dataset_config.json
│ ├── dataset_experiment_config.json
│ └── train_spec.json
├── heartratenet
│ ├── heartratenet.ipynb
│ ├── process_dataset.py
│ └── specs
│ ├── heartratenet_data_generation.yaml
│ └── heartratenet_tlt_pretrain.yaml
├── lprnet
│ ├── download_and_prepare_data.sh
│ ├── lprnet.ipynb
│ ├── preprocess_openalpr_benchmark.py
│ └── specs
│ ├── tutorial_spec_scratch.txt
│ ├── tutorial_spec.txt
│ └── us_lp_characters.txt
├── mask_rcnn
│ ├── maskrcnn.ipynb
│ └── specs
│ ├── coco_labels.txt
│ ├── create_coco_tf_record.py
│ ├── download_and_preprocess_coco.sh
│ └── maskrcnn_train_resnet50.txt
├── retinanet
│ ├── generate_val_dataset.py
│ ├── __init__.py
│ ├── retinanet.ipynb
│ └── specs
│ ├── retinanet_retrain_resnet18_kitti.txt
│ └── retinanet_train_resnet18_kitti.txt
├── ssd
│ ├── generate_val_dataset.py
│ ├── __init__.py
│ ├── specs
│ │ ├── ssd_retrain_resnet18_kitti.txt
│ │ ├── ssd_tfrecords_kitti_trainval.txt
│ │ └── ssd_train_resnet18_kitti.txt
│ └── ssd.ipynb
├── unet
│ ├── prepare_data_isbi.py
│ ├── prepare_data.sh
│ ├── specs
│ │ └── unet_train_resnet_unet_isbi.txt
│ ├── unet_isbi.ipynb
│ └── vis_annotation.py
├── yolo_v3
│ ├── __init__.py
│ ├── specs
│ │ ├── yolo_v3_retrain_resnet18_kitti.txt
│ │ └── yolo_v3_train_resnet18_kitti.txt
│ └── yolo_v3.ipynb
└── yolo_v4
├── __init__.py
├── specs
│ ├── yolo_v4_retrain_resnet18_kitti.txt
│ └── yolo_v4_train_resnet18_kitti.txt
└── yolo_v4.ipynb
39 directories, 108 files

So what’s next?

To read more about TLT 3.0, you can go to https://developer.nvidia.com/transfer-learning-toolkit.
